Simpson Power Washer Manual: A Comprehensive Guide
This manual details Simpson gas and electric power washers‚ including models PS3228‚ CM61083‚ and PS60843. It covers assembly‚ operation‚
maintenance‚ and troubleshooting for optimal cleaning performance.
Understanding Your Simpson Power Washer
Simpson power washers are designed for residential and light commercial use‚ offering a range of PSI and GPM options. Models like the PS3228 (3300 PSI‚ 2.5 GPM) utilize Honda GX200 engines‚ while others‚ such as the CM61083 (3400 PSI‚ 2.5 GPM)‚ feature CRX engines.
Understanding these specifications is crucial for selecting the right nozzle and pressure setting for various cleaning tasks. Proper operation ensures effective dirt and grime removal while protecting surfaces from damage.
Model Identification and Specifications
Simpson Cleaning offers diverse power washer models. The PS3228 PowerShot boasts a Honda GX200 engine‚ delivering 3300 PSI at 2;5 GPM‚ paired with a 25-foot MorFlex hose. The CM61083 provides 3400 PSI at 2.5 GPM with a CRX engine.
The PS60843 model achieves 4400 PSI at 4.0 GPM‚ also utilizing a CRX420 engine. Identifying your specific model is vital for accessing correct parts and maintenance procedures.
Safety Precautions
Always read this manual before operating your Simpson power washer. Wear safety glasses and closed-toe shoes during use. Never point the wand at yourself or others. Gas-powered models emit carbon monoxide; ensure adequate ventilation.
Keep children and pets away from the operating area. Do not modify the pressure washer or use incompatible accessories. Disconnect the power source before servicing. Follow all local safety regulations.
General Safety Rules
Understand your power washer’s capabilities and limitations. Avoid operating when fatigued or under the influence of drugs or alcohol. Never leave the machine unattended while running. Inspect hoses and connections before each use for damage.
Maintain a safe distance from electrical sources and flammable materials. Use appropriate nozzles for the cleaning task. Be aware of your surroundings and potential hazards. Store the unit securely when not in use.
Specific Warnings for Gas-Powered Models
Gasoline is highly flammable; handle with extreme caution. Refuel only when the engine is off and cool. Ensure adequate ventilation during refueling and operation to prevent carbon monoxide poisoning.
Never operate the unit indoors or in enclosed spaces. Check the oil level before each use and maintain proper levels. Be mindful of hot engine components and exhaust fumes. Store fuel in an approved container.
Component Overview
Simpson power washers feature robust engines‚ like the Honda GX200 or CRX series‚ powering high-pressure pumps. These pumps deliver varying PSI (pounds per square inch) and GPM (gallons per minute) for diverse cleaning tasks.
Essential components include a high-pressure hose‚ quick-connect nozzles‚ a spray gun‚ and an extension wand. The MorFlex hose is known for its durability and flexibility. Understanding each part ensures proper assembly and operation.
Engine Details (Honda GX200‚ CRX Engines)
Simpson power washers utilize reliable Honda GX200 engines known for their durability and performance. Alternatively‚ some models employ CRX engines‚ offering a cost-effective power source. These engines require regular oil changes and air filter maintenance for optimal operation.
Both engine types are air-cooled‚ four-stroke‚ and gasoline-fueled. Proper fueling procedures are crucial for safe and efficient running. Refer to the engine’s specific manual for detailed specifications and maintenance schedules.
Pump Specifications (PSI & GPM)
Simpson power washers feature pumps delivering varying pressure (PSI) and flow rate (GPM) to suit diverse cleaning tasks. The PS3228 model boasts 3300 PSI at 2.5 GPM‚ ideal for moderate cleaning. The CM61083 offers 3400 PSI at 2.5 GPM‚ providing increased power.
The PS60843 achieves 4400 PSI at 4.0 GPM‚ tackling heavy-duty jobs effectively. Understanding these specifications is vital for selecting the appropriate nozzle and cleaning technique.
Hose and Nozzle Attachments
Simpson power washers commonly include a 25-foot MorFlex hose‚ known for its durability and flexibility. Quick Connect (QC) nozzle attachments are standard‚ allowing for easy switching between spray patterns. Included nozzles typically range from 0-degree (intense cleaning) to 40-degree (gentle cleaning).
Additional nozzles‚ like the 25-degree‚ provide all-purpose cleaning capabilities. Surface cleaners are also available as attachments for efficient large-area cleaning.
Assembly Instructions
Before operation‚ proper assembly is crucial. Begin by connecting the MorFlex hose to both the pump and the water source‚ ensuring a tight fit. Next‚ securely attach the desired nozzle to the spray gun using the Quick Connect system. For gas models‚ carefully inspect all fuel lines before fueling.
Double-check all connections for leaks or damage before starting the engine. Refer to the diagrams in this manual for visual guidance during assembly.
Connecting the Hose
Attach the 25-foot MorFlex hose to the high-pressure outlet on the Simpson power washer pump. Ensure the connection is secure and hand-tightened‚ then slightly tighten with a wrench. Connect the garden hose to the water inlet on the pump‚ using appropriate adapters if needed. Verify no kinks or obstructions are present.
Always use a water supply with sufficient pressure and volume for optimal performance. Inspect the hose for damage before each use.
Attaching Nozzles
Simpson power washers utilize quick connect (QC) nozzles for easy interchangeability. Select the appropriate nozzle – 0°‚ 25°‚ or 40° – based on the cleaning task. Firmly push the nozzle onto the spray gun until it clicks securely into place. Ensure the nozzle is properly seated to prevent accidental disconnection during operation.
Always release the trigger before changing nozzles. Inspect nozzles for clogs or damage before each use.
Fueling the Engine (Gas Models)
Only use fresh‚ unleaded gasoline with a minimum octane rating of 87. Ensure the engine is cool before refueling‚ and avoid spilling gasoline. Slowly remove the fuel cap and add fuel‚ leaving space for expansion. Do not overfill the tank‚ and securely tighten the cap after fueling. Always fuel in a well-ventilated area.
Consider using a fuel stabilizer for extended storage.
Operating Instructions
Before starting‚ ensure all connections are secure – hose‚ nozzles‚ and fuel (gas models). Start the engine following the specific instructions for your model (refer to the starting section). Adjust the pressure settings to match the cleaning task; lower pressure for delicate surfaces. Maintain a safe distance and use proper spraying techniques‚ moving consistently.
Always wear safety glasses and appropriate clothing during operation.
Starting the Engine
For gas-powered models‚ ensure the fuel tank is filled with fresh gasoline. Turn the fuel valve to the ‘ON’ position and set the choke to ‘START’ if the engine is cold. Engage the safety lever on the spray gun. Pull the starter cord firmly and repeatedly until the engine starts; then gradually adjust the choke. Allow the engine to warm up before full operation.
Adjusting Pressure Settings
Simpson power washers offer adjustable pressure via unloader valves. Begin with the lowest setting to test a small‚ inconspicuous area. Gradually increase the pressure by turning the pressure adjustment knob‚ observing the cleaning effect. Avoid exceeding the recommended pressure for the surface being cleaned to prevent damage. Proper adjustment maximizes cleaning efficiency and protects materials.
Proper Spraying Techniques
Maintain a consistent distance from the surface – typically 8-12 inches. Use smooth‚ overlapping strokes‚ moving the nozzle evenly across the area. Avoid holding the nozzle too close‚ which can cause damage. Work from top to bottom to prevent streaking. Select the appropriate nozzle for the task‚ starting with a wider angle and increasing intensity as needed.
Maintenance Schedule
Regular maintenance extends your Simpson power washer’s life. Check the oil level before each use (gas models) and change it after every 50 hours. Clean the air filter after 25 hours of operation. Inspect nozzles for clogs and replace as needed. Flush the pump with pump saver solution during storage. Follow the manual for detailed schedules and procedures to ensure optimal performance.
Oil Changes (Gas Models)
Change the oil every 50 hours of operation‚ or annually‚ whichever comes first. Use SAE 30 oil‚ or 10W-30 for colder climates. Warm the engine before draining the old oil. Remove the oil drain plug and allow complete drainage. Refill with the correct amount of fresh oil‚ checking the dipstick. Dispose of used oil responsibly at a recycling center.
Air Filter Cleaning
Inspect the air filter every 25 hours of operation. Clean or replace as needed to maintain engine performance. Remove the air filter cover and carefully take out the filter. Tap the filter gently to remove loose debris‚ or use compressed air (inside to out). If heavily soiled‚ replace with a new filter. Reinstall and secure the cover tightly.
Nozzle Cleaning and Inspection
Regularly inspect nozzles for clogs or damage. Clogged nozzles reduce pressure and cleaning effectiveness. Remove the nozzle from the spray gun and inspect the orifice for obstructions. Use a nozzle cleaning tool or a thin wire to carefully clear any debris. Replace damaged nozzles immediately to prevent uneven spray patterns and maintain optimal performance.
Troubleshooting Common Issues
If the engine won’t start‚ check fuel levels‚ spark plug condition‚ and air filter cleanliness. For low pressure output‚ inspect the nozzle for clogs and verify proper water supply. Address water leaks by tightening hose connections and inspecting the pump for damage. Consult the full manual for detailed diagnostic steps and safety precautions before attempting repairs.
Engine Won’t Start
If your Simpson gas engine fails to start‚ first ensure sufficient fuel is present and the fuel valve is open. Check the spark plug for fouling or damage‚ replacing if necessary. A clogged air filter can also prevent starting; clean or replace it. Verify the engine’s low-oil sensor isn’t activated‚ adding oil if needed.
Low Pressure Output
Reduced pressure often indicates a partially clogged nozzle; remove and thoroughly clean all nozzles‚ checking for obstructions. Inspect the high-pressure hose for kinks‚ cuts‚ or damage‚ replacing if found. Ensure the water supply is fully open and provides adequate volume. A worn pump may require professional servicing or replacement to restore optimal pressure.
Water Leaks
Check all hose connections – ensure they are tight and properly secured to prevent leakage. Inspect the spray gun and wand for cracks or damage‚ replacing components as needed. Examine the pump for any visible leaks around the seals; professional repair may be required. Verify the water inlet hose is securely connected to both the water source and the power washer.
Nozzle Selection Guide
Choosing the right nozzle is crucial for effective cleaning. A 0-degree nozzle delivers a concentrated stream for intense cleaning of stubborn dirt and grime. The 25-degree nozzle is an all-purpose option‚ suitable for most surfaces. A 40-degree nozzle provides a wider‚ gentler spray for delicate surfaces like painted siding. Always test in an inconspicuous area first to avoid damage.
0-Degree Nozzle – For Intense Cleaning
The 0-degree nozzle produces a highly concentrated‚ powerful spray ideal for removing deeply embedded dirt‚ grime‚ and old paint from concrete or metal. Use extreme caution as this nozzle can easily damage softer surfaces like wood or vinyl siding. Maintain a safe distance and always test in an inconspicuous area before widespread application to prevent etching or surface removal.
25-Degree Nozzle – All-Purpose Cleaning
The 25-degree nozzle is your versatile‚ go-to option for a wide range of cleaning tasks around the home. Effectively cleans siding‚ brick‚ concrete‚ and garden furniture without causing significant damage. It provides a balanced spray pattern‚ removing dirt and grime efficiently. This nozzle is suitable for most exterior surfaces‚ offering a safe and effective cleaning solution.
40-Degree Nozzle – Gentle Cleaning
The 40-degree nozzle delivers a wider‚ lower-pressure spray‚ ideal for delicate surfaces. Perfect for washing cars‚ boats‚ and painted surfaces‚ minimizing the risk of damage. Effectively removes light dirt and grime without stripping paint or causing etching. This nozzle is also excellent for rinsing after applying detergents or cleaning solutions‚ ensuring a thorough clean.
Winterizing Your Simpson Power Washer
Proper winterization prevents freeze damage. Begin by stabilizing the fuel system with a fuel stabilizer‚ running the engine briefly to circulate it. Disconnect the water supply and drain all remaining water from the pump and hose. Add pump protector to safeguard internal components. Store the unit in a dry‚ protected area‚ covering it to prevent dust accumulation‚ ensuring longevity.
Fuel System Stabilization
Gasoline degrades over time‚ causing starting problems and carburetor issues. Add a fuel stabilizer to the gasoline tank before extended storage‚ following the manufacturer’s instructions. Run the engine for several minutes to ensure the stabilized fuel circulates throughout the fuel system – carburetor and fuel lines. This prevents varnish buildup and ensures easier starting when you need it again.
Pump Protection from Freezing
Water left inside the pump can freeze‚ causing significant damage to internal components. Disconnect the water supply and activate the trigger to relieve pressure. Use pump saver fluid specifically designed for pressure washers‚ following the product’s directions carefully. This prevents corrosion and cracking during freezing temperatures‚ ensuring your pump remains functional for the next cleaning season.
Understanding Quick Connect (QC) Nozzles
Simpson power washers often utilize Quick Connect (QC) nozzles for easy interchangeability. These nozzles simply push onto the spray gun and lock into place‚ offering a secure connection. The PS3228 model includes five QC nozzle tips‚ each providing a different spray pattern. Ensure the nozzle is firmly attached before operation to prevent accidental disconnection during use‚ maximizing cleaning efficiency.
MorFlex Hose Care and Replacement
Simpson power washers frequently feature a MorFlex hose‚ known for its durability and flexibility. Inspect the 25-foot hose regularly for kinks‚ cuts‚ or abrasions. Avoid sharp bends or dragging it across rough surfaces to prolong its lifespan. If damage occurs‚ replace the hose immediately to prevent leaks and maintain optimal pressure. Proper hose care ensures safe and effective operation of your Simpson power washer.
Simpson Cleaning PS3228 PowerShot Model Specifics
The Simpson PS3228 PowerShot boasts a 3300 PSI and 2.5 GPM output‚ driven by a Honda GX200 engine. This gas-powered model includes a spray gun‚ extension wand‚ and five quick-connect nozzles. Its 49-state compliance ensures broad usability. Regular maintenance‚ like oil checks and nozzle cleaning‚ is crucial. Always refer to the full manual for detailed operating and safety instructions specific to this model.
Simpson 3400 PSI Gas Pressure Washer (CM61083) Details
The Simpson CM61083 delivers 3400 PSI at 2.5 GPM‚ powered by a CRX engine designed for residential use. It features a 25-foot MorFlex hose and is marketed as a “Clean Machine” for effective cleaning. Proper assembly‚ including hose connection and nozzle attachment‚ is vital. Regularly inspect the universal 5-N-1 nozzle for wear and ensure optimal performance. Consult the manual for complete safety guidelines.
Simpson 4400 PSI Model (PS60843) Features
The Simpson PS60843 boasts 4400 PSI at 4.0 GPM‚ utilizing a CRX420 engine and a robust welded steel frame. This model is ideal for demanding cleaning tasks‚ offering increased power and efficiency. Ensure proper fuel handling and oil changes as outlined in the manual. Regular maintenance extends the lifespan of the unit. Always prioritize safety when operating this high-pressure washer.
Warranty Information and Support
Simpson Cleaning offers warranties on their power washers‚ varying by model and component. Refer to your specific product documentation for detailed coverage terms and conditions. For warranty claims or support‚ visit the Simpson Cleaning website or contact their customer service department. Proper maintenance‚ as detailed in this manual‚ is crucial for warranty validity. Retain your proof of purchase for all support inquiries.
